Size | PCD | Offset | Load Rating | Centre Bore |
---|---|---|---|---|
16x8 | 5/160 | 38 | 1497 | 65.1 |
16x8 | 6/120 | -10 | 1224 | 78.1 |
16x8 | 6/130 | 38 | 1497 | 84.1 |
16x8 | 6/139.7 | -10 | 1224 | 78.1 |
16x8 | 6/139.7 | -10 | 1224 | 112.1 |
Size | PCD | Offset | Load Rating | Centre Bore |
---|---|---|---|---|
17x8 | 5/110 | 30 | 1224 | 72.1 |
17x8 | 5/114.3 | 30 | 1224 | 74.1 |
17x8 | 5/114.3 | 30 | 1224 | 72.5 |
17x8 | 5/120 | 30 | 1224 | 74.1 |
17x8 | 5/127 | 30 | 1224 | 72.5 |
17x8 | 6/130 | 38 | 1224 | 84.1 |
17x9.5 | 5/127 | -18 | 1133 | 78.1 |
17x9.5 | 5/139.7 | -18 | 1133 | 78.1 |
17x9.5 | 5/139.7 | 0 | 1133 | 110.1 |
17x9.5 | 5/150 | 0 | 1133 | 110.1 |
17x9.5 | 6/135 | -18 | 1133 | 106.1 |
17x9.5 | 6/135 | 12 | 1133 | 106.1 |
17x9.5 | 6/139.7 | -18 | 1133 | 106.1 |
17x9.5 | 6/139.7 | 12 | 1133 | 106.1 |
17x9.5 | 8/165.1 | -18 | 1651 | 122.4 |
17x9.5 | 8/165.1 | 12 | 1651 | 122.4 |
17x9.5 | 8/170 | -18 | 1651 | 125.1 |
17x9.5 | 8/170 | 12 | 1651 | 125.1 |
17x9.5 | 8/180 | -18 | 1651 | 125.1 |
17x9.5 | 8/180 | 12 | 1651 | 125.1 |
Â
18 Inch
Size | PCD | Offset | Load Rating | Centre Bore |
---|---|---|---|---|
18x8 | 5/114.3 | 30 | 1224 | 74.1 |
18x8 | 5/114.3 | 30 | 1224 | 72.5 |
18x8 | 5/120 | 30 | 1224 | 74.1 |
18x8 | 5/127 | 30 | 1224 | 72.5 |
18x8 | 6/130 | 38 | 1224 | 84.1 |
18x9.5 | 5/127 | -18 | 1133 | 78.1 |
18x9.5 | 5/127 | 0 | 1133 | 78.1 |
18x9.5 | 5/139.7 | -18 | 1133 | 78.1 |
18x9.5 | 5/139.7 | 0 | 1133 | 78.1 |
18x9.5 | 5/139.7 | 12 | 1133 | 110.1 |
18x9.5 | 5/150 | 12 | 1133 | 110.1 |
18x9.5 | 6/135 | -18 | 1133 | 106.1 |
18x9.5 | 6/135 | 12 | 1133 | 106.1 |
18x9.5 | 6/139.7 | -18 | 1133 | 106.1 |
18x9.5 | 6/139.7 | 12 | 1133 | 106.1 |
18x9.5 | 8/165.1 | -18 | 1651 | 122.4 |
18x9.5 | 8/165.1 | 12 | 1651 | 122.4 |
18x9.5 | 8/170 | -18 | 1651 | 125.1 |
18x9.5 | 8/170 | 12 | 1651 | 125.1 |
18x9.5 | 8/180 | -18 | 1651 | 125.1 |
18x9.5 | 8/180 | 12 | 1651 | 125.1 |
Â
20 Inch
Size | PCD | Offset | Load Rating | Centre Bore |
---|---|---|---|---|
20x8.5 | 5/114.3 | 30 | 997 | 74.1 |
20x8.5 | 5/114.3 | 30 | 997 | 72.5 |
20x8.5 | 5/120 | 30 | 997 | 74.1 |
20x8.5 | 5/127 | 30 | 997 | 72.5 |
20x9.5 | 5/127 | -18 | 1133 | 78.1 |
20x9.5 | 5/127 | 0 | 1133 | 78.1 |
20x9.5 | 5/139.7 | -18 | 1133 | 78.1 |
20x9.5 | 5/139.7 | 0 | 1133 | 78.1 |
20x9.5 | 5/139.7 | 12 | 1133 | 110.1 |
20x9.5 | 5/150 | 12 | 1133 | 110.1 |
20x9.5 | 6/135 | -18 | 1133 | 106.1 |
20x9.5 | 6/135 | 0 | 1133 | 106.1 |
20x9.5 | 6/135 | 12 | 1133 | 106.1 |
20x9.5 | 6/139.7 | -18 | 1133 | 106.1 |
20x9.5 | 6/139.7 | 0 | 1133 | 106.1 |
20x9.5 | 6/139.7 | 12 | 1133 | 106.1 |
20x9.5 | 8/165.1 | -18 | 1651 | 122.4 |
20x9.5 | 8/165.1 | 12 | 1651 | 122.1 |
20x9.5 | 8/170 | -18 | 1651 | 125.1 |
20x9.5 | 8/170 | 12 | 1651 | 125.1 |
20x9.5 | 8/180 | -18 | 1651 | 125.1 |
20x9.5 | 8/180 | 12 | 1651 | 125.1 |
20x12 | 5/127 | -44 | 1133 | 78.1 |
20x12 | 5/139.7 | -44 | 1133 | 78.1 |
20x12 | 6/135 | -44 | 1133 | 106.1 |
20x12 | 6/139.7 | -44 | 1133 | 106.1 |
20x12 | 8/165.1 | -44 | 1651 | 122.4 |
20x12 | 8/170 | -44 | 1651 | 125.1 |
20x12 | 8/180 | -44 | 1651 | 125.1 |
